RI-CUST: Roll-In Shower Pan
Standard Features
- Size made to your specifications
- Solid one-piece cast marble
- Durable gel coat surface
- Pre-leveled-rests on subfloor
- Extremely sanitary
- Will not mold or mildew
- Easy to install
- Maintenance-free
- Manufactured in the U.S.A.
- Recommended: add Shower Pan Liners to protect pans during construction
Applications
- Designed for ADA compliant rooms
- Hospitality | Multifamily | Senior Living | Student Housing | Military Housing
Item Number
- RI-CUST
Technical Specifications
add
| Model | Custom Traditional, ADA Roll-In |
| Pan Size | Variable |
| Material | Cast Marble |
| Floor Pattern | Traditional |
| Finish | Matte, Textured, Non-Slip |
| Backwall | Variable - Up to 120" max on master |
| Side Walls | Variable - Up to 60" max on master |
| Drain Location | Must fit limitations of mold |
| Center of Drain Measures | Variable - based on final pan size |
| Dimensions | NOTE: Finished product dimensions may vary +/- 1/8" from drawings |
| Drain Opening | 3 1/4" |
| Front Curb | None. Floor will tile up to the entrance of the pan forming the ramp |
| Ramp | Provided by others |
| Flange | ~4" on side and back walls - attached at factory |
| Weight | Variable by size |
| Slope | Pan is sloped toward the drain at 2% |
| CSI Number | 22 42 23 |
Colors
add
Special Notes
add
Standards and Ratings:
- CSA B45-5/IAPMO Z124-2011
- MAS Certified Green. Compliant with ANSI/BIFMA X7.1 Standard
- ANSI A137.1 (average rating of 0.65)
- ANSI A326.3 (average rating of 0.72)
- ANSI/NFSI B101.3 (average rating of 0.66)
Suggested Drains:
- Sioux Chief Mfg. model: 825-2P – PVC
- Oatey part number: 42045 – PVC
- Oatey part number: 42150 – Brass
NOTE: Finished product dimensions may vary +/- 1/8" from drawings
NOTE: Drain is not included with pan
Resources
add
| Download | |||
|---|---|---|---|
| insert_drive_file | #RI-CUST Spec Sheet | cloud_download | mail_outline |
| insert_drive_file | Installation Instructions | cloud_download | mail_outline |
| insert_drive_file | Care and Maintenance | cloud_download | mail_outline |
| insert_drive_file | Master Specifications | cloud_download | mail_outline |
| insert_drive_file | Technical Drawings | cloud_download | mail_outline |
| live_tv | How to install a Mincey Marble Shower Pan | play_circle_outline | mail_outline |
